Microtek E2 UPS 1025 Sine Wave

Product Description

Microtek UPS E2- 1025VA Sine Wave UPS

MICRO CONTROLLER / DSP BASED DIGITAL SINEWAVE UPS EB are designed using latest state-of-the-art Technology for Better Performance and High Reliability. The Digital Sinewave Technology used enhances the life of the battery and minimum effort has to be put for maintenance.

Microtek UPS E2 1025VA Sine Wave Inverter Description
Pure Sine wave UPS suitable for running Load up to 900 Watts. Built with Micro Controller Based Intelligent Control Design and Pure Sine wave Output. It does not create any Humming Noise from Inductive Load such as Fans and it supports wide range of Batteries from 100 AH to 180 AH.

Rated Capacity

1025 VA / 12V

Output Power

900 Watts

Battery

1 Battery System (12 VDC)

Wave form

Sine wave

Warranty

2 Years

Microtek UPS E2 1025VA Sine Wave Inverter Key features

Micro Controller Based Intelligent Control Design.
LED Display Indications (Status & Fault)
CCCV Technology with Auto Trickle Mode
Smart Overload Sense and Short Circuit Protection
Battery State Monitoring
Multi Stage Battery Charger
Mains Input Voltage Range Slide Selection Switch

Display

MAINS ON
UPS ON
BATTERY CHARGING
OVERLOAD
BATTERY LOW
FAULT INDICATION

Protections

Over Load/Short Circuit Protection: If the UPS is excessively Overloaded in UPS Mode or encounters a Short Circuit, it will go into Protection Mode. The Output will Shut Down in this case.
Battery Deep Discharge/Over Charge Protection: The UPS has In-built Electronic Protection Circuit that protects the Batteries from getting Deep Discharged or Over Charged.

Technical Specifications

Input

Input Voltage (Standard range)

100 V ~ 300 V

Input Voltage (Narrow range)

180V ~ 260 V

Output

Output Voltage (Mains Mode)

Same as Input

Output Voltage (UPS Mode)

200V~ 230V ± 10%

Output Waveform (Mains Mode)

Same as Input

Output Waveform (UPS Mode)

Sinewave

Changeover

Switchover from Mains to UPS and UPS to Mains

Automatic

UPS Transfer Time

≤ 15 msec.

Technology

Design

Micro Controller Based Design with IPS Technology

Battery Charging Current

Constant Charging approx. 10% of the rated Battery Current in AH

UPS Overload / UPS Short-circuit

110% / 300%

Browns on Mains Voltage

100V ± 40V

Efficiency (Battery Mode)

> 80%

Auto Reset Feature

Yes

Input DC Range

10.5 V ~ 14.2 V

Charging Current (Standard)

10 Amps ± 1 Amps

Charging Current (High)

14 Amps ± 1 Amps
Microtek UPS E2 1025VA Sine Wave Inverter, best inverter for home use,
